Power Button: Press the button to power on the scooter; press and hold the button for 2 seconds to power it o. When the scooter is on, press the
button to turn on/o the headlight and the tail light, and press twice to switch between the speed modes.
Speedometer: It displays the current speed of the scooter, as well as error codes.
Walk Mode: The headlight and tail light are always on and can't be turned o.
Speed Mode: There are 3 modes available. The top speed is as follows:
* Ranges of Speed Modes: Tested while riding with a full battery, 75 ± 5 kg (165 ± 11 lbs) load, 25 ±5°C (77 ± 41 °F), at the max. speed of each speed
mode on average on pavement.
Left Directioin Indicator: When this icon blinks, it indicates that the direction indicators on the left side are turned on.
Right Directioin Indicator: When this icon blinks, it indicates that the direction indicators on the right side are turned on.
Error Notication: It indicates that the scooter has detected an error.
Temperature Warning: It indicates that the battery temperature has reached 55°C (131°F) or is below 0°C (32°F).
* At this point, the scooter cannot accelerate normally and may not be charged. Do not use until the temperature has reverted to the normal range.
Bluetooth: It indicates that the scooter has been successfully connected to the mobile device.
Battery Level: The total battery power equals 5 bars.
* The battery power is very low when the rst battery bar is red. Please charge your scooter immediately.
Locking Reminder: When the icon lights up, it means the scooter is locked. If abnormal movements are detected, the scooter will start beeping and
the tail light will falsh.
Diagram
1
EN EN
Dashboard & Power Button
Speedometer
Temperature Warning
Locking Reminder
Bluetooth
Speed Mode
Walk Mode
Headlight
Error Notication
Battery Level
Power Button
Model
Mode
E2 II Speed limit E2 Plus II Speed limit
15 km/h (9.3 mph)
20 km/h (12.4 mph)
20 km/h (12.4 mph)
15 km/h (9.3 mph)
20 km/h (12.4 mph)
25 km/h (15.5 mph)
E2 II Ranges*
25 km (15.5 miles)
20 km (12.4 miles)
20 km (12.4 miles)
E2 Plus II Ranges*
25 km (15.5 miles)
25 km (15.5 miles)
20 km (12.4 miles)
D (Standard mode)
E (Energy-saving mode)
S (Sport mode)
Bell
Handlebar
Electronic Throttle
Direction Indicator Switch
Left Direction Indicator
Right Direction Indicator
Left Direction Indicator
Right Direction Indicator
Snap Hook
Dashboard
Brake Lever
Headlight
Stem
Safety Button
Returning mark
Folding Mechanism
Quick-release Lever
Front Shock Absorber
Front Fender
Hub Motor
Charge Port
Footboard
Buckle
Rear Fender
Drum Brake
Tail Light &
Rear Reector
Side Reector
Front Reector
Kickstand
Battery Compartment
Power Button
License
Plate Holder
01 02
