DRAIN CONDENSATE INLET
(PIPING VARIES BY MODEL)
OPERATING AIR PRESSURE, CONNECT HERE AT AIR FILTER,
CUSTOMER SUPPLIED CLEAN DRY AIR AT 80 - 120 PSIG
CHECK VALVE
VENT NEEDLE VALVE
VALVE MUST BE ADJUSTED OPEN TO ALLOW
FOR FREE FLOW OF CONDENSATE INTO DRAIN.
DRAIN WILL NOT FUNCTION IF VALVE IS CLOSED.
VENT VALVE EXHAUST MUFFLER
REMOVE MECHANISM PROTECTIVE SHIPPING MATERIAL
AND INSTALL PIPE PLUG BEFORE PRESSURIZING DRYER
TEST BUTTON
DRAIN CONDENSATE INLET
DRAIN DISCHARGE VALVE
DRAIN VALVE ACTUATOR
