FRONT VIEW AIRCOOLED
AIR AND WATERCOOLED RIGHT SIDE VIEW
REAR VIEW
TOP VIEW
1.00
TYP
3.09
TYP
6.3173.50
6.75
16.50
34.00
79.94
O
.56 MTG HOLES
4 PLCS
CUSTOMER MAIN POWER
ELECTRICAL CONNECTION BOX
6"-300# R.F.S.O. FLANGE
AIR INLET CONNECTION
6"-300# R.F.S.O. FLANGE
AIR OUTLET CONNECTION
72.00
75.50
FRONT VIEW WATERCOOLED
76.00
2.00
TYP
32.00
90.69
3.00
10.50
4.75
5.00 86.00
COVER FOR
WATERCOOLED
HEADERS
90.00
24.0031.00
3.00
FORK POCKETS
6.00 X 2.50
A
DETAIL A (TYP)
AIR TREATMENT
CONTROL SYSTEM
LCD DISPLAY
1) CHILLER TEMP
2) COMPRESSOR ON/OFF
3) DRAIN INTERVAL
4) DRAIN ON
5) PERCENT SAVINGS
6) CUMULATIVE DRYER HOURS
7) CUMULATIVE COMPRESSOR HOURS
8) CUSTOMER SET POINTS
A) CHILLER TEMP
B) DRAIN INTERVAL
C) DRAIN ON
PUSHBUTTONS
1) ON
2) OFF
3) RESET
4) TEST
5) SET
6) SELECT DISPLAY
7) ENTER
8) +/-
1.38
1-1/2" MPT WATER
OUTLET CUSTOMER
CONN.
1-1/2" MPT WATER
INLET CUSTOMER
CONN.
CONDENSER FOR
AIRCOOLED UNITS
(REF)
SHOWN FOR
REFERENCE
CONDENSER AIR
DISCHARGE
CONDENSER AIR
DISCHARGE
CONDENSER AIR
DISCHARGE
CONDENSER AIR
INLET
CONDENSER AIR
INLET
CONDENSER AIR
INLET
CONDENSER AIR
INLET
CONDENSER AIR
INLET
4.06
18.69
1/2'' FPT CONNECTION
NO AIR LOSS DRAIN
7.56
6.50
CONDENSER FOR
WATERCOOLED UNITS
(REF)
DRAIN SHUT-OFF
VALVE
1/8'' NPT OPERATING
AIR PRESSURE PORT
(CUSTOMER SUPPLIED
80 - 120 PSIG)
NO AIR LOSS DRAIN ASSEMBLY
(FACTORY INSTALLED)
GENERAL ARRANGEMENT
D5635NCHP & D7055NCHP
AIR AND WATERCOOLED, NEMA-1
550108
