Model KA24E
Type Gasoline, 4-cycle
Cylinder arrangement 4-cylinder in-line
Bore × Stroke in (mm) 3.504 × 3.780 (89.0 × 96.0)
Displacement cu in (cm
3
) 145.78 (2,389)
Firing order 1-3-4-2
Idle speed rpm
See the ‘‘Emission Control
Label’’ on the underside of the hood.
Ignition timing (BTDC) degree/rpm
CO percentage at idle speed [No air] %
Spark plug ZFR4E-11 (Hot)
ZFR5E-11 (Standard)
ZFR6E-11 (Cold)
Spark plug gap in (mm) 0.039 to 0.043 (1.0 to 1.1)
Camshaft operation Timing chain
Generator belt size
Width × Length in (mm) 0.429 × 36.81 (10.9 × 935)
The spark ignition system of this ve-
hicle meets all requirements of the
Canadian Interference - Causing
Equipment Regulations.
ENGINE
9-9
