TOP STRAP CHILD RESTRAINT
If your child restraint has a top strap, install
the anchor bracket to one of the provided
anchor points. Secure the child restraint with
either the 2-point or 3-point seat belt and
latch the top strap hook onto the appropriate
anchor bracket. If using the 3-point seat belt,
make sure the shoulder belt is placed be-
tween the seat back and child restraint. To
install the anchor bracket, a metric bolt of the
dimensions listed below must be used.
Bolt diameter: 8.0 mm
Bolt length: more than 1.18 in (30 mm)
Thread pitch: 1.25 mm
The top strap should be secured to the
attaching belt which provides the straightest
installation of the top strap.
WARNING
Child restraint anchor points are de-
signed to withstand only those loads
imposed by correctly fitted child re-
straints. Under no circumstances are
they to be used for adult seat belts or
harnesses.
APD0711
2-28
ZX
