Nissan 2011 Leaf - Alternate Procedure 1 for HV System Shut-Down

Alternate Procedure 1
1. Open the hood.
2. Press and expand the pawls (A) on the sides of the fuse box and remove the fuse box (1) from its
housing.
NOTE:
There is no separate fuse box cover. The bottom of the fuse box is also its cover.
3. Remove the following fuses:
a. VCM IGN fuse (F15 VCM IGN 10A)
b. F/S1 RLY Fuse (F24 F/S1 RLY 15A)
c. VCM Fuse (F3 VCM 20A)
