9-4 Monitor system (if so equipped)
distance on the hill is the place
*
B
. Note that
any object on the hill is closer than it appears on
the monitor.
Backing up near a projecting object:
The predicted course lines
*
A
do not touch the
object in the display. However, the vehicle may
hit the object if it projects over the actual
backing up course.
Backing up behind a projecting object:
The position
*
C
is shown further than the
position
*
B
in the display. However, the
position
*
C
is actually at the same distance
as the position
*
A
. The vehicle may hit the
object when backing up to the position
*
A
if
the object projects over the actual backing up
course.
HOW TO PARK WITH PREDICTED
COURSE LINES
WARNING
. Always turn and check that it is safe
to park your car before backing up.
Always back up slowly.
. Use the displayed lines as a refer-
ence. The lines are highly affected
by the number of occupants, vehicle
position, road condition and road
grade.
. If the tires are replaced with differ-
ent sized tires, the predicted course
line may not be displayed correctly.
. On a snow-covered or slippery road,
there may be a difference between
the predicted course line and the
actual course line.
. If the battery is disconnected or
becomes discharged, the predicted
course lines may not be displayed
correctly. If this occurs, perform the
following procedures.
