Nissan 2016 Leaf - MOTOR; WHEELS AND TIRES

MOTOR
Model EM57
WHEELS AND TIRES
Road wheel
Type Size Offset in
(mm)
Steel 16 × 6 1/2J 1.57 (40)
Aluminum 16 × 6 1/2J 1.57 (40)
Aluminum 17 × 6 1/2J 1.77 (45)
Tire
Tires Size
205/55R16
215/50R17
DIMENSIONS AND WEIGHTS
Overall length in (mm) 175.0 (4,445)
Overall width in (mm) 69.7 (1,770)
Overall height in (mm) 61.0 (1,550)
Front tread
w/ 16 inch wheels in (mm) 60.6 (1,540)
w/ 17 inch wheels in (mm) 60.2 (1,530)
Rear tread
w/ 16 inch wheels in (mm) 60.4 (1,535)
w/ 17 inch wheels in (mm) 60.0 (1,525)
Wheelbase in (mm) 106.3 (2,700)
Gross Vehicle Weight Rating
(GVWR)
lb (kg)
Refer to the F.M.V.S.S. or C.M.V.S.S. certifi-
cation label on the driver’s side center pillar.
Gross Axle Weight Rating (GAWR)
Front lb (kg)
Rear lb (kg)
9-6 Technical and consumer information
