1. Tachometer
2. Speedometer
3. Trip computer
4. Trip odometer reset switch/Instrument
brightness control
5. Continuously Variable Transmission
(CVT) position indicator (CVT models
only)
6. Odometer/twin trip odometer/Outside
air temperature (if so equipped)
7. Outside Air Temperature (if so
equipped)
8. Fuel gauge
CAUTION
● To clean the meter lens, use a soft cloth,
dampened with water. Never use a
rough cloth, alcohol, benzine, thinner or
any kind of solvent or paper towel with
a chemical cleaning agent. They will
scratch or cause discoloration to the
lens.
● Do not spray any liquid such as water on
the meter lens. Spraying liquid may
cause the system to malfunction.
SPEEDOMETER AND ODOMETER
This vehicle is equipped with a speedometer and
odometer. The speedometer is located on the
right side of the meter cluster. The odometer is
located within the trip computer.
Speedometer
The speedometer indicates the vehicle speed.
Type B (if so equipped)
LIC3341
2-4 Instruments and controls
