1. Rear headrests (Page 1-8)
2. Child restraint anchor points (for top tether strap
child restraint) (P.1-31)
3. Head restraints (P.1-4)
— Front-seat Active Head Restraints (P.1-7)
4. Roof-mounted curtain side-impact supplemental
air bags (P.1-35)
5. Seat belts (P.1-10)
6. Front seats (P.1-3)
7. Supplemental front-impact air bags (P.1-35)
8. LATCH (Lower Anchors and Tethers for CHildren)
system* (P.1-19)
9. Rear seats (P.1-4)
— Child restraints (P.1-18)
10. Front seat-mounted side-impact supplemental air
bags (P.1-35)
11. Seat belt with pretensioners (P.1-47)
12. Occupant classification sensors (weight sensors)
— Advanced Air Bag System (P.1-41)
13. Front passenger air bag status light (P.1-42)
SEATS, SEAT BELTS AND
SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
0-2 Illustrated table of contents
