Black plate (302,1)
Model "F15-D" EDITED: 2010/ 6/ 24
EXTERIOR AND INTERIOR LIGHTS
Item Wattage (W) Bulb No.
Headlight high/low beams (Halogen) 65/55 HB5
Front turn signal light* 21 PY21W
Front fog light (if so equipped)* 35 H8
Front side marker* 3.8 194
Front park light 5 WY5W
Side turn signal light* 5 WY5W
Rear combination light*
stop light 21 W21W
turn signal/tail/rear side marker light 21/5 W21/5W
back-up 16 W16W
License plate light*
5 W5W
Map light 5 —
High-mounted stop light* LED —
Cargo light 5
—
*: See a NISSAN dealer for replacement.
NOTE: Always check with the Parts De partment at a NISSAN dealer for the latest information about parts.
SDI2306
: REMOVE
: INSTALL
Replacement procedures
All other lights are either type A, B, C, D or E.
When replacing a bulb, first remove the lens
and/or cover.
8-26 Maintenance and do-it-yourself
