ENGINE
Model MR16DDT
Type Gasoline, 4-cycle, DOHC
Cylinder arrangement 4-cylinder, in-line
Bore 6 Stroke in (mm) 3.138 6 3.193 (79.7 6 81.1)
Displacement cu in (cm
3
) 98.78 (1,618)
Firing order 1-3-4-2
Idle speed rpm
No adjustment is necessary.
Ignition timing (B.T.D.C.) degree/rpm
Spark plug Standard DILKAR7C9H
Spark plug gap (Normal) in (mm) 0.035 (0.9)
Camshaft operation
Timing chain
This spark ignition system complies with the Canadian standard ICES-002.
WHEELS AND TIRES
Road wheel
Type Size Offset in (mm)
Aluminum 17 6 7J 1.85 (47)
Spare 16 6 4T
1.18 (30)
Tire
Type Size
Pressure PSI
(kPa) [Cold]
Conventional
P215/55R17
93V
33 (230)*1
36 (250)*2
34 (240)*3
Spare
T135/80D16
101M*1*2
60 (420)
T135/90D16
102M*3
*1: 2WD MT model
*2: 2WD CVT model
*3: AWD model
SPECIFICATIONS
Technical and consumer information 9-7
