Model "F15-D" EDITED: 2010/ 6/ 24
SPA2809
Loose fuel cap warning message
Push the reset button
*
A
for more than 1
second to reset the LOOSE FUEL CAP warning
message after the fuel cap has been tightened.
For additional information see “FUEL-FILLER
CAP” in the “3. Pre-driving checks and adjust-
ments” section of this manual.
SIC4506
TACHOMETER
The tachometer indicates engine speed in
revolutions per minute (RPM). Do not rev the
engine into the red zone
*
1
.
CAUTION
When engine speed approaches the red
zone, shift to a higher gear or reduce
engine speed. Operating the engine in
the red zone may cause serious engine
damage.
SIC4123
ENGINE COOLANT TEMPERATURE
GAUGE
The gauge
*
1
indicates the engine coolant
temperature.
The engine coolant temperature is within the
normal range when the gauge is within the zone
*
2
shown in the illustration.
The engine coolant temperature varies with the
outside air temperature and driving conditions.
2-6 Instruments and controls
