QUICK REFERENCE CHART LEAF
QUICK REFERENCE CHART LEAF PFP:00000
TUNE-UP DATA (EM61) ELS0003W
FRONT WHEEL ALIGNMENT ELS0003X
Measure value under unladen*
2
conditions.
*1: A difference when assuming the left side a standard.
*2: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
REAR WHEEL ALIGNMENT ELS0003Y
Measure value under unladen* conditions.
*: Fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and mats are in designated positions.
Motor model EM61
Cooling system leakage testing pressure
kPa (kg/cm
2
, psi)
32 (0.3, 5)
Camber
Degree minute (Decimal degree)
Minimum –1° 10′ (–1.16°)
Nominal –0° 25′ (–0.42°)
Maximum 0° 20′ (0.33°)
Left and right difference*
1
–0° 45′ (–0.75°) - 0° 45′ (0.75°)
Caster
Degree minute (Decimal degree)
Minimum 4° 05′ (4.09°)
Nominal 4° 50′ (4.83°)
Maximum 5° 35′ (5.58°)
Left and right difference*
1
–0° 45′ (–0.75°) - 0° 45′ (0.75°)
Kingpin inclination
Degree minute (Decimal degree)
Minimum 11° 10′ (11.17°)
Nominal 11° 55′ (11.92°)
Maximum 12° 40′ (12.66°)
Toe-in
To ta l t o e - in
Distance
Minimum In 1 mm (0.04 in)
Nominal In 2 mm (0.08 in)
Maximum In 3 mm (0.12 in)
Toe angle (left wheel or right wheel)
Degree minute (Decimal degree)
Minimum In 0° 02′ 46′′ (0.046°)
Nominal In 0° 05′ 28′′ (0.091°)
Maximum In 0° 08′ 09′′ (0.136°)
Camber
Degree minute (Decimal degree)
Minimum –1° 59′ (–1.98°)
Nominal –1° 29′ (–1.48°)
Maximum –0° 59′ (–0.99°)
To e - in
Total toe-in
Distance
Minimum In 1.5 mm (In 0.06 in)
Nominal In 5.5 mm (In 0.22 in)
Maximum In 9.5 mm (In 0.37 in)
Toe angle (left wheel or right wheel)
Degree minute (Decimal degree)
Minimum In 0° 04′ 05′′ (In 0.068°)
Nominal In 0° 14′ 56′′ (In 0.249°)
Maximum In 0° 25′ 48′′ (In 0.43°)
