CAUTION
Do not operate the windshield wiper
while arm is pulled up. The wiper arm or
hood may be damaged.
Replacing
1. Push the release tab
䊊
A
, and move the wiper
blade down the wiper arm
䊊
1
while pushing
the release tab to remove.
2. Insert the new wiper blade onto the wiper arm
until a click sounds.
3. Rotate the wiper blade so that the dimple is in
the groove.
CAUTION
• After wiper blade replacement, return
the wiper arm to its original position;
otherwise it may be damaged when
the hood is opened.
• Make sure the wiper blades contact
the glass; otherwise the arm may be
damaged from wind pressure.
Be careful not to clog the washer nozzle
䊊
A
. This
may cause improper windshield washer opera-
tion. If the nozzle is clogged, remove any objects
with a needle or small pin
䊊
B
. Be careful not to
damage the nozzle.
8-14 Maintenance and do-it yourself
