[ Edit: 2016/ 11/ 24 Model: E12-A ]
E12-A-120227-D62826F9-535D-41D4-8DE9-C84CC2669783
WARNING:
. Gasoline is extremely flammable and highly
explosive under certain conditions. You
could be burned or seriously injured if it is
misused or mishandled. Always stop the
engine and do not smoke or allow open
flames or sparks near the vehicle when
refueling.
. Fuel may be under pressure. Turn the cap a
half of a turn, and wait for any “hissing”
sound to stop to prevent fuel from spraying
out and possibly causing personal injury.
Then remove the cap.
. Use only an original equipment type fuel-
filler cap as a replacement. It has a built-in
safety valve needed for proper operation of
the fuel system and emission control sys-
tem. An incorrect cap can result in a serious
malfunction and possible injury.
OPENING FUEL-FILLER LID
E12-A-120227-95A82A38-55CE-4E0A-9F7A-10CBD38B4CE7
JVP0130X
To open the fuel-filler lid, pull the fuel-filler lid release
handle
*
1
.
FUEL-FILLER CAP
E12-A-120227-98BFD1BD-43B1-45EB-936E-C2CB4B4F180B
JVP0131X
The fuel-filler cap is a ratcheting type. Turn the cap
counterclockwise
*
1
to remove. Tighten the cap
clockwise
*
2
until ratchet clicks, more than twice,
after refueling.
Put the fuel-filler cap on the cap holder
*
A
while
refueling.
CAUTION:
If fuel is spilled on the vehicle body, flush it away
with water to avoid paint damage.
E12-A-120227-31CC0B0E-A592-42F3-A713-0D2C8E3E5286
WARNING:
Never adjust the steering wheel while driving so
that full attention may be given to vehicle
operation.
SPA2225
While pushing the lock lever down
*
1
, adjust the
steering wheel up or down
*
2
until the desired
position is achieved.
Pull the lock lever up
*
3
firmly to lock the steering
wheel in place.
Pre-driving checks and adjustments 3-15
FUEL-FILLER LID STEERING WHEEL
