WARNING
•
Before closing the bonnet and to avoid injury
or damage, make sure there are no obstacles
around the bonnet.
•
The bonnet must be closed and latched se-
curely before driving. Failure to do so could
cause the bonnet to fly open and result in an
accident.
•
Never open the bonnet if steam or smoke is
coming from the engine compartment to
avoid injury.
OPENING BONNET
1. Pull the bonnet lock release handle j1 located
below the instrument panel until the bonnet
springs up.
2. Locate the lever
j2 in between the bonnet and
grille and push the lever sideways with your fin-
gertips.
3. Raise the bonnet
j3.
4. Remove the support rod
j4 and insert it into the
slot
j5.
Hold the coated parts
jA when removing or re-
setting the support rod. Avoid direct contact with
the metal parts, as they may be hot immediately
after the engine has been stopped.
JVP0127XZ
BONNET
Pre-driving checks and adjustments 3-19
