WARNING
Be sure the ignition switch is placed in the
“LOCK” position.
Visually inspect each belt for signs of unusual wear,
cuts, fraying or looseness. Check regularly for con-
dition and tension. If the belt is in poor condition or
loose, have it replaced or adjusted by a NISSAN
dealer or qualified workshop.
1.
Water pump
2.
Alternator
3.
Crankshaft pulley
4.
Air conditioner compressor
▼:
Tension checking point
1.
Supercharger
2.
Water pump
3.
Alternator
4.
Electromagnetic clutch
5.
Crankshaft pulley
6.
Drive belt auto-tensioner
7.
Air conditioner compressor
1.
Crankshaft pulley
2.
Drive belt auto-tensioner
3.
Alternator
4.
Air conditioner compressor
▼:
Tension checking point
SDI2573Z
HR12DE engine
JVM0061X
HR12DDR engine
NDI1256
K9K engine
DRIVE BELTS
