STC-28
< DTC/CIRCUIT DIAGNOSIS >
C1607, C1608 EPS CONTROL UNIT
C1607, C1608 EPS CONTROL UNIT
DTC Logic INFOID:0000000007207883
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.DTC REPRODUCTION PROCEDURE
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is DTC
“C1607” or “C1608” detected?
YES >> Proceed to diagnosis procedure. Refer to STC-28, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis Procedure INFOID:0000000007207884
1.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Erase self-diagnosis results for “EPS”.
3. Perform “EPS” self-diagnosis.
Is DTC
“C1607” or “C1608” detected?
YES >> Replace EPS control unit. Refer to STC-40, "Removal and Installation".
NO >> Check EPS control unit pin terminals for damage or loose connection with harness connector. If
any item are damaged, repair or replace error-detected parts.
DTC Display item Malfunction detected condition Possible cause
C1607 EEPROM
When the memory (EEPROM) system malfunction is
detected in EPS control unit.
EPS control unit
C1608 CONTROL UNIT
When the internal malfunction is detected in EPS
control unit.
Revision: March 2013 2012 Versa Sedan
