STC-32
< DTC/CIRCUIT DIAGNOSIS >
EPS WARNING LAMP
EPS WARNING LAMP
Component Function Check INFOID:0000000007207894
1.CHECK THE ILLUMINATION OF THE EPS WARNING LAMP
Check that the EPS warning lamp turns ON when ignition switch turns ON. Then, EPS warning lamp turns
OFF after the engine is started.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Perform trouble diagnosis. Refer to STC-32, "Diagnosis Procedure"
.
Diagnosis Procedure INFOID:0000000007207895
1.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Turn the ignition switch OFF to ON.
2. Perform “EPS” self-diagnosis.
Is any DTC detected?
YES >> Check the DTC. Refer to STC-13, "DTC Index".
NO >> GO TO 2.
2.CHECK EPS WARNING LAMP SIGNAL
With CONSULT
1. Turn the ignition switch ON.
CAUTION:
Never start the engine.
2. Select “DATA MONITOR” of “EPS” and select “WARNING LAMP”.
3. Check that the EPS warning lamp is turned ON.
4. Start the engine.
CAUTION:
Never drive the vehicle.
5. Check that the EPS warning lamp is turned OFF.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for combination meter power supply circuit. Refer to MWI-43,
"COMBINATION METER : Diagnosis Procedure" (Type A) or MWI-92, "COMBINATION METER :
Diagnosis Procedure" (Type B).
NO >> Replace the EPS control unit. Refer to STC-40, "Removal and Installation"
.
Revision: March 2013 2012 Versa Sedan
