STC-36
< SYMPTOM DIAGNOSIS >
STEERING WHEEL TURNING FORCE IS HEAVY OR LIGHT
3. Select “TORQUE SENSOR” in “DATA MONITOR” in “EPS”.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
7.CHECK EPS MOTOR
Perform the trouble diagnosis of EPS motor. Refer to STC-26, "Diagnosis Procedure"
.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace the specific malfunctioning part.
8.CHECK STEERING WHEEL TURNING FORCE
Check the steering wheel turning force. Refer to ST-4, "Inspection"
.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Check the steering wheel turning force for mechanical malfunction. Refer to ST-4, "Inspection"
.
Monitor item Condition Display value
TORQUE SENSOR
Steering wheel: Not steer-
ing (There is no steering
force)
Approx. 0 Nm
Steering wheel: Right turn Positive value (Nm)
Steering wheel: Left turn Negative value (Nm)
