WARNING
∙ When sitting in the rear seat, do not
hold onto the seatback of the front
seat. If the side air bag inflates, you
may be seriously injured. Be espe-
cially careful with children, who
should always be properly restrained.
Some examples of dangerous riding
positions are shown in the
illustrations.
∙ Do not use seat covers on the front
seatbacks. They may interfere with
side air bag inflation.
NISSAN Advanced Air Bag System
(front seats)
1. Crash zone sensor
2. Supplemental front-impact air bag
modules
3. Air bag Control Unit (ACU)
4. Occupant classification sensor (weight
sensor – located in front passenger
cushion frame)
5. Roof-mounted curtain side-impact
and rollover supplemental air bag
6. Side satellite sensor
7. Seat belt with pretensioner(s) (front
seats)
8. Front seat-mounted side-impact
supplemental air bag modules
9. Front door satellite sensor (driver’s side
shown; front passenger side similar)
WRS0032 LRS2906
Safety—Seats, seat belts and supplemental restraint system 1-51
