Nitecore HC33 User Manual

R1SLVOARD Thrbo HIGH MID LOW ULTRALOW STROBE SOS Beacon
18000
lumens
780
lumens
240
lumens
70
lumens
1
lumens
1800
lumens
1800
lumens
1800
lumens
30min 1h45min 5h45mIn 16h30min 330h — — —
187m 117m 63m 35m 4m — — —
8750cd 3400cd 1000cd 300cd 4.5cd — — —
1m (Impect Resistant
1p68,2m(waterproof AND submersible)
NOTE: The above data has been measured in accordance with the international
flashlight testing standards ANSI/NEMA FL1, using 1×18650 battery (3500mAh) under laboratory conditions.
The data may vary in real-world use due to different battery use or environmental conditions. The runtime for
Turbo or High mode is the testing result before starting temperature regulation.
The Turbo 1800 lumens requires the use of rechargeable IMR18650 or 18650 Li-ion batteries with output
current higher than 8A. The Turbo is not accessible with CR123A or RCR123A batteries.
Installation of the diffuser

Nitecore HC33 Specifications

General

Product color	Black
Flashlight type	Headband flashlight
Housing material	-
Adjustable headband	Yes
Battery type	18650/CR123
Battery life (max)	330 h
Number of batteries supported	1
LED type	CREE XHP35 HD
Lamp type	LED
Light color	White
Luminous flux	1800 lm
Lamps quantity	1 lamp(s)
Flashlight modes	SOS mode, Strobe mode
Luminous intensity	8750 cd
Light beam distance (max)	187 m

Weight and Dimensions

Width	105.3 mm
Weight	51.2 g
Head diameter	25.5 mm
