Nokia 109, C1-02i
(RM-907)
L1L2 Service Manual
13
Nokia Internal Use Only | Copyright © 2012 Nokia | All rights reserved
V ersion 1.0
7) Release also the other side of the A-COVER with
the SRT-6.
8) Remove the A-COVER.
9) Protect the DISPLAY with protective film.
10) Protect also the other side of the A-COVER
with protective film.
11) Push out the KEYMAT as shown and remove it.
12) Unscrew the four TORX+ size 4 screws in the
order shown.
