CA-41PS Power cable
Power cable for connection of e.g. the JBV-1 docking station to the
FPS-10 prommer box.
CA-52PS DC Cable
The cable is used to connect JBV-1 docking station to the phone
charger jack for ADC/VCHAR/ICHAR calibration.
DA-64 Docking station
adapter
The docking station adapter is used for this phone in combination with
JBV-1. The adapter supports flashing and energy management
calibration,
Features include:
• compatible with JBV-1
• easy phone attachment and detachment
• reliable phone locking
• switch for detecting phone
• replaceable SIM interface
DAU-9S MBUS cable
The MBUS cable DAU-9S has a modular connector and is used, for
example, between the PC's serial port and module jigs, flash adapters
or docking station adapters.
Note: Docking station adapters valid for DCT4 products.
RM-258; RM-259
Service Tools and Service Concepts
Page 2 –6 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
