Nokia 3410 Manual

CONFIDENTIAL 12 (44)
NHM—2/5/6 Repairhints
Customer Care Europe, Middle East & Africa 3410 Version 4.0 Approved
SCCE Training Group Date 20.11.2002
© NMP 2002
Checked by:
Customer Care E&A
Approved by:
SCCE Training Group
Correct component replacement in UB4_ 10 or later of NHM-5 (SB053) and NHM-6 (SB31)
If changing the power amplifier (N502) & antenna switches (Z502) is necessary, it is recommended to replace with the same type
as the removed one.
The information in tables “PA vendor depent RF discrete component mount” and “Ant.sw./diplexer depent RF discrete components
mounts” in NHM-5/6 Service Manual must be followed if there is a really essential reason to use different type of power
amplifier or antenna switch as replacement
Only the following combinations of power amplifier and antenna are allowed for NHM-5/6:
Note:
- After changing Power Amplifier, TX Power Tuning has to be carrying out.
- After changing Antenna Switch, Tx Power Tuning and RX Calibrations have to be carrying out.
After the Power Amplifier replacements, additional it should be checked in which constellation R311 and R312 were assembled
(marked “X”).
If necessary, adjust the resistors in the corresponding order to the type of PA.
Use for it the table below (PA vendor detection) as reference. (NHM-5; SB 25)
This is important because of the differences between the three power amplifier versions in use.
In UP4 Hitachi PA has been used while UD4 includes Philips PA and UG4 uses RFMD power amplifier.
Last mentioned is available as spare part meanwhile.
For PCB version up to Version 09 PCB version 10 and later
PA vendor detection
PA vendor Part. No. R312 (PA_vendor2) R311 (PA_vendor1)
RFMD 435X231 Mounted
Phillips 435X194 Mounted
Hitachi 4350259
NHM-5
Power Amplifier Antenna Switch
Hitachi (4350259) Murata (4550131)
Phillips (4350269) Matushita (4550201)
RFMD (4350277)
Matushita (4550201)
NHM-6
Power Amplifier Antenna Switch
Hitachi (4350259) Murata (4550131)
Phillips (4350269) Murata (4550131)
PA vendor detection
PA vendor Part. No. R312 (PA_vendor2) R311 (PA_vendor1)
RFMD 435X231 Mounted Mounted
Phillips 435X194 Mounted
Hitachi 4350259 Mounted

Nokia 3410 Specifications

General

Weight	114 g (4.02 oz)
Network Technology	GSM
2G bands	GSM 900 / 1800
GPRS	No
EDGE	No
Status	Discontinued
SIM	Mini-SIM
Memory Card slot	No
Phonebook	Yes
Call records	10 dialed, 10 received, 10 missed calls
Camera	No
Alert types	Vibration; Downloadable monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Clock	Yes
Alarm	Yes
Java	No
Predictive text input	Yes
SMS to many	Yes
Calculator	Yes
Stopwatch	Yes
Xpress-on covers	Yes
WAP	No
Vibrating alert	Yes
Ringtones	Monophonic
FM radio	No
Bluetooth	No
Infrared port	No
USB	No
Display	Monochrome graphic
Battery	Removable Li-Ion battery
Stand-by time	Up to 260 h
Released	2002
Announced	2002
Games	Snake II, Space Impact, Bantumi
