Nokia 6111 - About your device

4
3
VBAT ~4V
VFlash1 = 2.8V
Customer Care / Service & Support Readiness / Content Creation Management
Copyright © 2005 NOKIA Only for training and service purposes
Version: 1.0 21.10.2005
6111 RM-82 Page 8(9)
Signal overview
Board version: 1mra_08a
1
3) SCL at R3302
1) Sleepclock at C6004
4) SDA at R3301
2) VSIM at X2700
5) CCI_SCL at R3325
6) CCI_SDA at R3324
VIO = 1.8V
VCAM = 1.8V
5
6
Lights on = 10.75V
without SIM
with 3V SIM card
