Nokia 7210 SAS-M Configuration Guide

Interface Configuration
7210 SAS M, T, X, R6, R12, Mxp, S, Sx Interface Configuration Guide Page 255
Show CardState Output — The following table describes show card state output fields.
Sample Output
*A:MTU-A# show card state
===============================================================================
Card State
===============================================================================
Slot/ Provisioned Equipped Admin Operational Num Num Comments
Id Type Type State State Ports MDA
-------------------------------------------------------------------------------
1 iom-24g iom-24g up up 2
1/1 m24-100fx-1gb-s* m24-100fx-1gb-s* up up 24
A sfm-24g sfm-24g up up Active
===============================================================================
* indicates that the corresponding row element may have been truncated.
Sample output for 7210 SAS-X:
A:7210-SAS-X> show card state
===============================================================================
Card State
===============================================================================
Slot/ Provisioned Equipped Admin Operational Num Num Comments
Id Type Type State State Ports MDA
-------------------------------------------------------------------------------
1 iom-sas iom-sas up up 2
1/1 m24-1gb+2-10gb m24-1gb+2-10gb up up 26
Label Description
Slot/MDA
The slot number of the card in the chassis.
Provisioned Type
The card type that is configured for the slot.
Equipped Type
The card type that is actually populated in the slot.
Admin State
Up — The card is administratively up.
Down — The card is administratively down.
Operational
State
Up — The card is operationally up.
provisioned — There is no card in the slot but it has been pre-
configured.
Num Ports
The number of ports available on the MDA.
Num MDA
The number of MDAs installed.
Comments
Indicates whether the SF/CPM is the active or standby.
