Interface Configuration
7210 SAS M, T, X, R6, R12, Mxp, S, Sx Interface Configuration Guide Page 323
Oversize Pckts : 0 Jabbers : 0
Collisions : 0
Octets : 3468749
Packets : 25439
Packets of 64 Octets : 25370
Packets of 65 to 127 Octets : 4987
Packets of 128 to 255 Octets : 10937
Packets of 256 to 511 Octets : 0
Packets of 512 to 1023 Octets : 0
Packets of 1024 to 1518 Octets : 0
Packets of 1519 or more Octets : 0
===============================================================================
Ethernet-Like M edium Statistics Output F ields Ethernet-like Medium Statistics Output — The following table describes Ethernet-like medium
statistics output fields.
Ethernet-like Medium Statistics — the following table describe Ethernet-like Medium Statistics field..
Label Description
Alignment Errors
The total number of packets received that had a length (excluding
framing bits, but including FCS octets) of between 64 and 1518 octets,
inclusive, but had either a bad Frame Check Sequence (FCS) with an
integral number of octets (FCS Error) or a bad FCS with a non-integral
number of octets.
FCS Errors
The number of frames received on a particular interface that are an
integral number of octets in length but do not pass the FCS check.
SQE Errors
The number of times that the SQE TEST ERROR is received on a par-
ticular interface.
Label Description
Alignment Errors
The total number of packets received that had a length (excluding
framing bits, but including FCS octets) of between 64 and 1518 octets,
inclusive, but that had either a bad Frame Check Sequence (FCS) with
an integral number of octets (FCS Error) or a bad FCS with a non-inte-
gral number of octets.
FCS Errors
The number of frames received that are an integral number of octets in
length but do not pass the FCS check.
SQE Errors
The number of times that the SQE TEST ERROR is received.
CSE
The number of times that the carrier sense condition was lost or never
asserted when attempting to transmit a frame.
