Interface Configuration
7210 SAS M, T, X, R6, R12, Mxp, S, Sx Interface Configuration Guide Page 33
Port Dot1q VLAN Etype
7210 SAS-T Yes
Yes
a
Yes
b
Yes
c
7210 SAS-R6 IMM
(IMMv1) and IMM-b
(IMMv2)
Yes Yes Yes No
7210 SAS-R6 IMM-c
(also known as IMM-c
1CFP4 or IMM-c
1QSFP28)
No Yes No No
7210 SAS-R12 IMM-b Yes Yes Yes No
7210 SAS-R12 IMM-c
100GE
2 variants - IMM-c
1CFP4 or IMM-c
1QSFP28)
No Yes No No
7210 SAS-Mxp Yes Yes Yes No
7210 SAS-Sx/S 1/
10GE
Yes Yes Yes No
7210 SAS-Sx 10/
100GE
Yes Yes Yes No
a Network ports can be configured only if the BOF is configured to operate the node in net-
work mode (also known as, MPLS mode).
b Hybrid ports are supported only when the node is operating in network mode.
c Access-uplink ports can be configured only if the BOF is configured to operate the node in
access-uplink mode (also known as, L2 mode).
Note: 7210 SAS-Mxp, 7210 SAS-Sx/S 1/10GE, 7210 SAS-Sx 10/100GE, 7210 SAS-R6,
and 7210 SAS-R12 is configured in Network mode by default. It does not support access-
uplink mode.
Table 6: 7210 SAS Platforms supporting port modes
Port Mode
Platforms
Access Network Hybrid Access-
uplink
