7368 ISAM ONT G-240W-J Product Guide Configure a G-240W-J indoor ONT
Issue: 01 3FE-48009-AAAA-TCZZA 131
Figure 52 DMZ and ALG window
Table 44 describes the fields in the DMZ and ALG window.
Table 44 DMZ and ALG parameters
Field
Description
ALG Config
Select the checkboxes to enable the protocols to be supported by the ALG: FTP,
TFTP, SIP, H323, RTSP, L2TP, IPSEC, PPTP
DMZ Config
WAN Connection List
Choose a WAN connection from the drop-down menu
Enable DMZ
Select this checkbox to enable DMZ on the chosen WAN connection
DMZ IP Address
Choose Customer Setting and enter the DMZ IP address or choose the IP address
of a connected device from the drop-down menu
2 Configure ALG.
4 Configure DMZ.
5 Click Save DMZ.
6 STOP. This procedure is complete.
3
Click Save ALG.
