Nokia 7500b Service Manual

11
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
7500 RM-249 / RM250
Page (18) ISSUE 2
Service Manual Level 1&2
DISASSEMBLY INSTRUCTION12.
1. Nokia 7500 Disassembly.
2. You will need the Nokia Standard Toolkit version 2 as well
as the camera removal tool SS-45. Also refer to the General
Mechanical Guideline Video for additional hints about the tools
and component handling.
3. Cover all sensitive surfaces with a protective lm. Unlock
and remove the C-COVER ASSY. Remove the battery if inserted.
4. Place the SRT-6 between the A-COVER ASSY and the KEYPAD
and gently unlock the clips starting at the shown side.
5. Repeat the same on the opposite side.
6. Remove the KEYPAD from the A-COVER.

Nokia 7500b Specifications

General

Brand	Nokia
Model	7500b
Category	Mobile phones
Language	English
