Radius operation
23
Radius operation
The use of a Radius server on the current AP
range can be enabled using the web pages or
via the command line, either through the serial
port or via Telnet.
Once enabled, whenever a wireless station
attempts to authenticate with the AP, the
following interaction with the Radius server
occurs:
The basic message flow between different
external entities is shown above.
Station AP Radius Server
MAC (Auth. Req., seq=1)
Access-Req
Access-Accept
MAC (challenge, seq=2)
username, password)
(optional encrypted
WEP key)
MAC (challenge response,
MAC (Authentication Res,
seq=3)
seq=4)
