Nokia G-2426G-B - Figure 8-26 US Classifier Policy Page; Table 8-22 US Classifier Policy Parameters

Configure
a
G
-
2426G
-
B
indoor
ONT
Network configuration
Configuring Upstream (US) Classifier
Nokia
ONT
3FE-49441-ABAA-TCZZA
June
2021
Issue 1
142
Figure 8-26 US Classifier Policy page
2
Select a tunnel interface.
Table 8-22 US Classifier Policy parameters
Field Description
Tunnel Type The tunnel type is set to GRE and cannot be modified.
Tunnel Interface Select a tunnel interface from the list: No Tunnel, GRE Tunnel, or LAN traffic.
VLAN ID Enter a VLAN ID (0-4094).
VLAN Tag This field is not configurable. The VLAN tag is set to 8100 (hexadecimal).
VLAN Priority Enter a VLAN priority level (0 to 7). A lower number indicates a higher priority.
IP TOS/DSCP This field is not configurable. All tunnel packets are generated with a default DSCP value
(usually 0).
Drop Select this checkbox to drop the packets.
3
Click Save.
Click Reset to reset the policy configured.
Click Refresh to view the up-to-date information.
