Nokia WiFi Beacon 6 Product Guide
Issue: 01 3FE-47429-AAAA-TCZZA 45
Note 1 — Observe the local and national laws and regulations that
may be applicable to this installation.
Note 2 — Observe the following:
• The device should be installed in accordance with the
applicable requirements of the NEC or CEC. Local
authorities and practices take precedent when there is
conflict between the local standard and the NEC or
CEC.
• The device must be installed by qualified service
personnel.
• Indoor units must be installed with cables that are
suitably rated and listed for indoor use.
• See the detailed specifications in the Beacon 6
(HA-0336G-A) unit data sheet for the temperature
ranges for these devices.
Install a Beacon 6 (HA-0336G-A)
6.6 Procedure
Use this procedure to install a Beacon 6 (HA-0336G-A).
1 Place the unit on a flat surface, such as a desk or shelf.
Note — The Beacon 6 (HA-0336G-A) cannot be stacked with another or
with other equipment. The installation requirements are:
• allow a minimum 100 mm clearance above the top cover
• allow a minimum 50 mm clearance from the side vents
• do not place any heat source directly above the top cover or below the bottom
cover
2 Review the connection locations, as shown in Figure 9.
