Nokia Lumia 1020 Disassemble Guide

Breakdown
Nokia Lumia 1020 – Disassemble Guide
Page 7 of 7
hp://www.fixez.com/
1. Nokia Lumia 1020 Rear Cover and Housing
2. Nokia Lumia 1020 Battery
3. Nokia Lumia 1020 Motherboard
4. Nokia Lumia 1020 Display Assembly (LCD & Touch Screen)
5. Nokia Lumia 1020 Locking Bar
6. Nokia Lumia 1020 SIM Card Tray
7. Nokia Lumia 1020 Headphone Jack Assembly
8. Nokia Lumia 1020 Front-Facing Camera Assembly
9. Nokia Lumia 1020 Rear-Facing Camera Assembly
Noce/Warning:
FIXEZ.COM DOES NOT ACCEPT ANY LIABILITY FOR DAMAGE, OR INJURY CAUSED, WHILE YOU ARE
FOLLOWING OUR DISASSEMBLE GUIDES. WE MAKE NO REPRESENTATIONS, WARRANTIES, OR
CONDITIONS OF ANY KIND, EXPRESS OR IMPLIED. UTILIZING THESE GUIDES TO HELP ASSIST YOU IN
REPAIRING YOUR MOBILE DEVICES WILL VOID YOUR WARRANTY. FIXEZ.COM STRICTLY PROHIBITS ALTER-
ING OR MODIFYING OUR DISASSEMBLE GUIDES FOR COMMERCIAL USE, REPRODUCTION, OR PUBLICA-
TION.
1
3
6
7
9
4
2
8
5

Nokia Lumia 1020 Specifications

General

Display	4.5 inches, AMOLED, 768 x 1280 pixels
RAM	2 GB
Operating System	Microsoft Windows Phone 8, upgradable to 8.1
Chipset	Qualcomm MSM8960 Snapdragon S4 Plus
CPU	Dual-core 1.5 GHz Krait
GPU	Adreno 225
Weight	158 g (5.57 oz)
Dimensions	130.4 x 71.4 x 10.4 mm (5.13 x 2.81 x 0.41 in)
Network	GSM / HSPA / LTE
Front Camera	1.2 MP, 720p
Internal Storage	32 GB
Battery	Li-Ion 2000 mAh, non-removable
Camera	41 MP, OIS, Xenon flash, LED flash
