N90-3
REMOVABLE INNER COMFORT PADDING
1 DISASSEMBLY
Deactivate the VPS and lift the helmet chin guard to remove and/or install the comfort
padding (see instructions above).
1.1 Open the chin strap (see specic instructions) and remove the chin strap band
from the elastic loop on the liner strap (Fig.14).
1.2 Pull the front of the left cheek pad inside the helmet to unhook its two snap fas-
teners from the left frame (Fig. 15). Repeat the same operation on the right side of
the helmet.
1.3 Release the left and right side aps of the liner from the shell edge by slightly pull-
ing the comfort padding inwards (Fig.16). Follow the same steps for the two rear
aps.
1.4 Hold the left front part of the liner and pull it upwards in order to remove the cor-
responding liner ap from the support xed to the polystyrene inner shell (Fig.17).
Then repeat the operation with the central front ap and with right ap.
1.5 Remove left and right side aps of the comfort padding from the cavities between
the inner polystyrene cheek pads and the outer shell (Fig.18).
1.6 Remove the chin strap bands from the liner (Fig. 19).
1.7 Completely remove the liner from the helmet.
2 ASSEMBLY
2.1 Insert the liner correctly into the helmet and have it well tted against the base.
2.2 Insert the chin strap band into the corresponding slot in the liner at the area of the
cheek pads (Fig.19). Follow the previous operations on the right side of the helmet.
2.3 Insert the right and left side aps of the liner by pushing them into the cavities
between the inner polystyrene cheek pads and the outer shell (Fig.18).
2.4 Insert the left front ap of the liner into the corresponding seat on the support xed
to the polystyrene inner shell and push it downwards until it is completely hooked.
Repeat the operation with the central and right ap too (Fig.17).
Check the correct assembly of the liner front area by lifting and lowering the
VPS whose movement should be unhindered. Otherwise, repeat operations 1.4
and 2.4.
2.5 Insert the left and right side aps and rear ones of the liner into the corresponding
support seats in the shell edge (Fig.16). Push the aps until they are fully hooked
onto the support.
2.6 Push the padding of the cheek pad at the snap fasteners located at the rear by
fastening them to the relevant seat of the frame xed to the shell (Fig.15).
2.7 Insert the chin strap band into the elastic loop on the liner strap (Fig. 14).
WARNING
- Remove the inner comfort padding only when cleaning or washing is required.
- Never use the helmet before completely and correctly reassembling its inner com-
fort padding.
- Carefully wash by hand and use only neutral soap and water at 30° max.
- Rinse using cold water and dry at room temperature, away from direct sunlight.
- Never machine-wash the inner comfort padding.
