NORDAC FLEX (SK 200E ... SK 235E) – Users Manual for Frequency Inverters
210 BU 0200 en-3118
Pos: 56 5 /Anl eitu ngen/El ektr onik/ FU und St arter /5. Par ameter /Par ameter aufl istung (P000 ...)/P 700-P7 99/P aramet er P708 – Zust and D igi tal eing äng e [ SK 2 xxE] @ 2\mod_1346932204549_388.docx @ 43464 @ @ 1
P708
Status of digital input
(Status of digital input)
00000 ... 11111 (bin)
or
0000 ... FFFF (hex)
Displays the status of the digital inputs in binary/hexadecimal code. This display can be used to
check the input signals.
Bit 0 = Digital input 1
Bit 1 = Digital input 2
Bit 2 =
Digital input 3
Bit 3 = Digital input 4
Bit 4 = Thermistor input
Bits 5 - 7
reserved
Pos: 56 6 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P7 00-P7 99/Par amet er P708 – Zustan d Di git alei ng äng e_Tei l 2/2 [ SK 1 x0 E, SK 2xxE , SK 2xxE-F DS] @ 9\ mod_1448441143299_388.docx @ 266679 @ @ 1
First SK xU4-IOE (optional)
Bit 8 = 1: IO extension: Digital input 1
Bit 9 = 1: IO extension: Digital input 2
Bit 10 = 1: IO extension: Digital input 3
Bit 11 =
1: IO extension: Digital input 4
Second SK xU4-IOE (optional)
Bit 12 = 2: IO extension: Digital input 1
Bit 13 = 2: IO extension: Digital input 2
Bit 14 = 2: IO extension: Digital input 3
Bit 15 =
2: IO extension: Digital input 4
Bits 15-12 Bits 11-8 Bits 7-4 Bits 3-0
Minimum value
0000
0
0000
0
0000
0
0000
0
Binary
hex
Maximum value
1111
F
1111
F
1111
F
1111
F
Binary
hex
SimpleBox: The binary bits are converted to a hexadecimal value and displayed.
ParameterBox: The Bits are displayed increasing from right to left (binary).
