NORDAC PRO (SK 500P) – Users Manual for Frequency Inverters
10 BU 0600 en-2319
Characteristic SK … 500P/510P 530P 550P
Additional information
Operating manual BU 0600
Legend
x = Present - = Not present O = Optionally available
External 24 V DC supply for the
control board voltage supply with
automatic switch-over between the
internal and external 24 V DC
power supply
– x x
 Section 2.5.4
RS-232 diagnostic interface via
RJ12 connection
x x x
RS-232 diagnostic interface via
USB-C connection
– x x
RS-485 interface via RJ12
connection
x x x
USS and Modbus RTU on board
x
x
x
CANopen on board x x x
Industrial Ethernet on board
–
–
x

BU 0620
Plug in data storage via µSD card
(for exchange of parameters)
– x x
 Section 2.5.4
Parameters pre-set with standard
values
x x x
 Section 5
4 switchable parameter sets
x
x
x
Parameterisation with
NORDCON-Software,
NORDCON APP or external
ParameterBox SK …-3H / -3E via
RJ12
x x x
Parameterisation possible with
NORDCON-Software via USB
interface without mains connection
or 24 V DC power supply ("in the
box")
– x x
Programmable direct current
braking
x x x
 Section 5.1.2, P108
Energy-saving function (automatic
load-dependent flux optimisation)
x x x
 Section 8.6
