STEP 2

1. Attach the front stabilizer (68) onto the Main

Frame (69) with 2 Carriage Bolts (44).

2. Attach the Rear Stabilizer (43) onto the Main

Frame (69) with 2 Carriage Bolts (44).

STEP 3

1. Screw the right Pedal (31R) into the right

pedal crank. (NOTE: The screw direction is

clockwise).

2. Screw the left Pedal (31L) onto the left pedal

crank. (NOTE: The screw direction is anti-clock-

wise).

STEP 4

1. Put the Handlebar Post (12) into the

Main frame (69) through computer rack

(10) and front plastic cover (60).Connect

The upper computer cable (27) and the lower

Computer cable (28)

Fit the Allen Bolt (26),spring washer (25)

Washer (24) and curved washers (70)

and align handlebar post so it is straight.

Then tighten the Allen bolts fully.
