10
4. Cut and remove the shipping tie (G) from each
side of the Base (64) (only one side is shown).
4
64
G
6
5. Make sure that the holes in the Carriage
Brackets (82) are aligned with the holes in the
Frame (83). If necessary, grip both sides of the
frame assembly (H) near the rear and push
forward or pull backward to align the holes. It
may also be helpful to move the frame assembly
from side to side or to lift the frame assembly
slightly.
Attach each Carriage Bracket (82) with two
3/8" x 1" Screws (6) (only one side is shown);
start all four Screws, and then tighten them
as firmly as possible.
H
82
83
5
