6.
4 Brush the inside of housing and Razor Head Assembly.
5 Replace the Razor Head Assembly back on razor.
Every Two Months: Razor Heads
1 Turn razor OFF and disconnect from outlet.
2 Remove Razor Head Assembly off housing unit.
3 Brush the inside of the housing.
4 Turn Razor Head Assembly over so that the
underside is exposed.
5 Press down and turn wheel of frame counterclockwise.
6 Remove the frame and brush clean.
7 Remove and clean one cutter and head at a time.
• Be careful not to mix up cutters and heads.They
are a matched set and if interchanged,it will greatly
affect shaving performance.
