222 System maintenance
• Building Information
The Building Information pane shows overall data related to the DECT
cluster.
•
DAP Information
The DAP Information pane shows data of the selected DAP.
Table 32
Buttons on the Synchronization Analyzer main page
Button Function
Load Location Click Load Location to open a specific Location file.
View Location Click View Location to open the Location page without specifying a Location
file.
See “Synchronization Analyzer Location page” (page 223).
Settings Click Settings to open the Settings page, where you can enter the RSSI
threshold and the Phase Difference threshold.
Find Click the Find button to search the RPN number, the MAC address, or Info
field of all the DAPs.
Table 33
Menus on the Synchronization Analyzer main page
Menu
Contains these options
File
•
Open
Choose Open to open a Visibility File.
•
Compare
Choose Compare to open a Visibility file and compare it with the current tree.
One of the following symbols appears next to each DAP in the tree view.
Symbol
Meaning
+ Red The current level of an RPN is higher that the one in the
compared file.
- Red The current level of an RPN is lower that the one in file
loaded for comparison.
= Green The current level is the same as the compared level.
X Red This DAP does not exist in the file that you loaded for
comparison.
• Print
Choose Print to send the Tree view to a printer.
• Exit
Choose Exit to exit from the program.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
