Note
If a signal is input to the MAIN INPUT and to the AUX IN at the same
time, you should check the phase of their signals. The signal could be
canceled by phase errors and will therefore not be amplified as expec-
ted: Please check the correlation by choosing different modes via the
MONO
L and MONO R buttons. In case of cancellations try to invert the
phase of the AUX signal and compare the results.
Specifications
Design 6 channel headphone amplifier with
equalizer and variable aux input per channel
Frequency response 20 Hz to 50KHz, +0/-2dB (no equalization)
Maximum gain 25.6dB @ 1kHz (no equalization)
Equalizer Treble EQ: ± 12 dB @ 10kHz, shelving filter
Bass EQ: ± 12 dB @ 100 Hz, shelving filter
Inputs XLR and 1/4“ TRS jacks (MAIN INPUT),
balanced and unbalanced pin assignment
1/4“ TRS jack (Aux inputs)
Input impedance 40kΩ (MAIN: balanced XLR and 1/4“ TRS jacks)
9.9kΩ (Direct In: 1/4“ jack)
15 to 21kΩ (AUX IN: 1/4“ TRS jacks)
Maximum output level +21.5dBu
Dynamic range ≥101dB typ. @ 130mW, 600Ω load, max. level
Outputs XLR and 1/4“ TRS jacks (MAIN THRU)
1/4“ TRS jacks (headphone outputs)
Output impedance ≤12Ω
Max. output level 600 Ω headphone: 150 mW (1 kHz)
32 Ω headphone: 500 mW (1 kHz)
8 Ω headphone: 150 mW (1 kHz)
Dimensions 44.5 x 482.6 x 190.5mm (H x W x D)
Weight 3.1kg
Power supply internal power supply, switchable between
115V, 60Hz and 230V, 50Hz
Consumption 18W idle, 60W max.
Reference: 0dBu = 0.775 VAC RMS
Scope of supply
Hexacon:
1 pc
P
ower cord:
1 pc
User manual:
1 pc
Disclaimer
No
wsonic has taken all possible steps to ensure that the information
given here is both correct and complete.
In no event can Nowsonic accept any liability or responsibility for any
loss or damage to the owner of the equipment, any third party, or any
equipment which may result from use of this manual or the equip
-
ment which it describes.
S
ervicing
If you have any question or encounter technical issues, please first
contact your local dealer from whom you have purchased the device.
In case servicing is required, please contact your local dealer. Other-
wise you may contact us directly. Please find our contact data on our
w
ebsite under www.nowsonic.com.
NOTE: We take great care in packing the device in a well protected
box at the factory, so any shipping damage is very unlikely. Howe-
ver, should this happen please contact your supplier immediately to
r
eport the damage. We recommend to keep the original packing ma-
terials in case you need to ship or transport the device at a later date.
L
egal information
Copyright for this user manual © 2013: Nowsonic
Product features, specifications and availability are subject to change
without prior notice.
Edition v1.0, 08/2013
Hexacon_Bedienungsanleitung_DINA4_V02.indd 8 24.10.13 15:10
