Pair and length measurement (PAIR & LENGTH) function:
The tester is capable to have pair and length (PAIR & LENGTH)
measurement with or without remote recognizer.
After entering into “PAIR & LENGTH” function, the tester shall start pair
and length (PAIR & LENGTH) test and it will display as follows to indicate
the measurement is being undertaken:
----T e s t i n g ----
1 2 3 4 5 6 7 8 . . .
Note:In view of different technical parameters in various brand cables,
the user should calibrate the cable length before length measurement
(Refer to the details herein).
Test Result 1: Short circuit (SHORT)
It will display as follows if there is any short circuit in cable or terminal:
(12 short circuit in the sample)
S h o r t :
1 2
Test Result 2: Normal pair and length (PAIR &LENGTH) display
P a i r 1 2 1 0 0 . 0 m
P a i r 7 8 9 9 . 8 m
P a i r 3 6 1 0 0 . 3 m
P a i r 4 5 1 0 0 . 2 m
At the moment, push key to restart test or push key toreturn
the main menu.
It will display as follows if pair and length(PAIR & LENGTH)
measurement is in normal condition:
PAIR&L
