Test result 5 : Normal 6 cores telephone cable
If you want to test Telephone cable , one side insert the main tester RJ11
interface and the other side connect nothing , then choose Telephone test
mode , after that choose cable length , and press OK , the result will show
you directly.
From the image , you can see the cable length is 95.6M , press return
the main menu and start other testing.
Test result 6: 6 cores of telephone cable with short circuit
If you want to test Telephone cable , one side insert the main tester RJ11
interface and the other side connect nothing , then choose Telephone test
mode , after that choose cable length , and press OK , the result will show
you directly.
The cable length is 95.6M, #1 & #2 has a short circuit in the location of
30.8M.
Test result 7: BNC cable length test
If to insert one end of the BNC cable to be tested into “BNC” port of the main
tester, the other end is an open circuit, select “BNC(2)” mode, return to the
main menu, and select length test, and then press “ENTER” key to perform
length test with the equipment, the following interface will be shown:
This result show you the cable length is 60.2M , press back to main menu
and enter other testing.
Test result 8 : BNC cable length test with short circuit
If to insert one end of the BNC cable to be tested into “BNC” port of the main
tester, the other end is an open circuit, select “BNC(2)” mode, return to the
main menu, and select length test, and then press “ENTER” key to perform
length test with the equipment, the following interface will be shown:
This result show you the cable length is 20.7M , press back to main menu
and enter other testing.
