Fig. 5. Equatorial Mounting:
 - folding clips; 2 - micrometer screw of slow-motion mechanism;
3 - declination axis; 4 - circle of declinations; 5 - counterweights;
6 - bolt; 7 - bracket with scale of latitudes; 8 - electric watch drive;
9 - handwheel of micrometer screw of polar axis;
0 - polar axis;  - circle of hour angles; 2 - screw of axis brake
