NRS EasyFit Plus+ - Technical Specification

PTDS052
EasyFit Plus
+
Bedrail
Technical Specicaon
Symbol Descripon Dimension
OW Overall Width 522mm ( 20
1
/
2
“)
OL Overall Length 712mm (28”)
OHS Overall Height Standard 820mm (32
1
/
4
“)
OHT Overall Height Tall 920mm (36
1
/
4
“)
HW Handrail Width 285mm (11
1
/
4
“)
TBS Top Bar Height Standard 692mm (36
1
/
4
“)
TBT Top Bar Height Tall 792mm (27
1
/
4
“)
CH Clamp Height Min Min: 30mm (1
1
/
5
“) Max:330mm (13“)
BW Base Width 301mm (11
7
/
8
“)
BD Base Depth 180mm (7“)
BH Base Tube Height 29mm (1
1
/
8
“)
- Max User Weight 25st ( 160kg)
Installaon Informaon: (Note: for detailed informaon refer to User Instrucons)
 Push the handrail onto the base.
 Posion the bedrail in the desired locaon at the side of the bed, slide the clamps up unl they
contact the underside of the bed frame and lock in posion.
 Turn the ratchet lever to provide the nal ghtening acon to ensure the clamps are ght
underneath the bed frame.
