ACCESORIES:
The Fuzz comes with:
- neoprene Chain Stay protector
- set of self-adhesive protective foil
- shock fender
The neoprene CS protector should be placed over the rear-derailleur cable to protect it and the frame from the chain.
Please refer to the diagram for correct location of each sheet on the frame.
Please de-grease and clean the surface of the frame before applying the protective foil on your frame.
SS (R)
SS (L)
CS (L)
CS (R)
TT
DT
Self-adhesive protective foil set might be used to additionally protect
the top tube, down tube, chain stays and seat stays.
To install the shock fender place it first inside the
shock cage so it sits firmly on the ribs inside the
shock cage and run zip-ties through the fender
holes and over shock hardware on the CS yoke
and tighten them.
FUZZ
