1.3 PARTS YOU PROVIDE
• PCB-mount switches (Cherry MX footprint)
• Keycaps
• BIT-C or other Pro Micro MCU
• [Optional] Qty. 40 Mill-Max 0305 or 7305 hot-swap solder sockets
1.4 OPTIONAL ADD-ONS AND EXTRAS [BOLD ARE NOT INCLUDED]
• WS2812B RGB LED underglow
• Rotary encoder & knob
• TRRS expansion jack for future numpad support
• SSD1306 OLED display
• Adafruit Mini 8x8 LED Matrix w/I2C Backpack LINK
• 16x8 1.2" LED Matrix w/I2C Backpack LINK
• Quad Alphanumeric Display - 0.54 w/I2C Backpack LINK
1.5 TOOLS REQUIRED
• Fine-tip soldering iron & solder
• Needle nose pliers
• Phillips #0 screwdriver
• Snips for cutting leads
• Rubbing alcohol
